Optical Magnification and Digital Magnification:

Binocular Microscope Magnification:
Mag. = Objective Mag. x Auxiliary Lens Mag. x Eyepiece Mag.

Trinocular Microscope Magnification:
Optical Mag. = Objective Mag. x Auxiliary Lens Mag. x Video Coupler Mag.
Digital Mag. = Monitor Diagonal (mm) / CCD Sensor Diagonal (mm)

Monitor

Monitor Size (Diagonal)

CCD Sensor Size

9 inch

230mm

12 inch

300mm

13 inch

330mm

18 inch

490mm

20 inch

510mm

21 inch

540mm

25 inch

640mm

27 inch

690mm

29 inch

740mm

To convert from inch to mm multiply by 25.4
